Required less skilled labor for most types of foundations.

In addition, when the structure is constructed on sloping ground, a pier foundation could be more suitable as they do not require are area to cover like pad footings. When with the increase of the load, concrete or reinforced concrete pipes could be constructed. For example, for structures having low weight, simpler foundations like timber piers could be used. When there are adequately strong hard soil strata or bedrock is closed, these types of foundations can be used for the construction.ĭepending on the nature of the structure, the type of foundation could be selected.

When and where to construct Pier Foundation.

Therefore, not like masonry or concrete pier foundation, reinforced concrete piers have higher structural capacity. Provided reinforcement increases the axial capacity as well as the bending capacity. Reinforced concrete piers are constructed where the applied axial loads are comparatively higher.

Construction of Reinforced Concrete Piers.

Other shapes such as helical shapes found in old structures.Types of material sued for the construction.The following figure indicates the three main types of concrete caisson foundation in addition to the masonry pier foundation. Concrete caissons with concrete and steel core in the steel pipe.Concrete caissons are constructed by filling concrete into the steel pipe.Drilled caissons with enlarged bottom constructed from concrete.Mainly there are three types of foundations. Further, excavation for these types of foundations could be done with mechanical means. The intention is to use the concrete or caisson types of foundation to carry higher axial loads applied from the superstructures.ĭrilled caissons are constructed up to the deeper depth when compared to the masonry/concrete pier foundations. That is piers rest on the hard soil or rock connected by the bases slab and start another set of piers based on the supporting requirement of superstructures.ĭrilled caisson are cylindrical shape foundations that are constructed from concrete. Structure supported on the combination of piers.Piers constructed at regular spacing could be observed in these types of foundation systems. Structure directly supporting on pier foundation rested on the hard soil layer.There are different types of pier foundations. Mostly the concrete piers are in circular, square, or rectangular shapes due to the difficulties in constructing other shapes. The size or the diameter of the concrete pier is comparatively smaller when compared to the masonry pier due to its high load-bearing capacity. Concrete PiersĬoncrete piers were also constructed to serve the same purpose as masonry pier foundations.

Further, the construction of pier foundations was common earlier to 1950. There are many old structures constructed as pier foundations in old-time even where the concrete was not invented. The masonry pier foundation could be constructed in different shapes such as circular, rectangular, hexagonal, etc. When the depth to the hard soil layer increases, it is very difficult to construct the foundation of this nature. The depth of the masonry pier could be continued up to 4-5m. Masonry piers are constructed when there are hard soil layers at the shallower depths. There are three main types of pier foundations. Pier foundation is types of foundations that are constructed from small scale to larger in scale when compared to the other types of foundations.Īs the name implies, a pier foundation is a combination of large diameter piers constructed to support the structure to transfer its loads to the ground.Ĭlassification of the foundation is made based on the method of construction or considering the nature of the structure.
